------------Southern Pacific Steam Locomotive Blueprints - rescued by Bayshore Machinist Fred Boland

In 1958, after steam was done on Southern Pacific, somebody decided that the volumnuous collection of no-longer-needed steam locomotive drawings filed away at San Francisco's Bayshore Shops could be eliminated. Shop personnel thus began to fill a dumpster with many hundreds of drawings, much to the distress of the late Machinist Fred Boland. By then, Fred had accumulated nearly 40 years of Bayshore service, and these drawings held sentimental value for him, since he had worked with them throughout his long career. But moreover, he recognized their historical significance. Figuring that nobody cared, he began collecting them for preservation. Unfortunately, in that regard he was wrong. When his foreman discovered what Fred was doing, he ordered him to cease his efforts - these were "company secrets" that had to be destroyed, lest they fall into the wrong hands. Never-mind that they were obsolete, and that many of them were essentially those of suppliers that had been redrawn by SP draftsmen to conform to its Common Standard drawings.

Despite the admonition, Fred eventually managed to sequester more than 150 drawings and related documents, all reproduced here. Fred's son, Walter, kindly went to considerable effort to digitize them for presentation here.

Fred's life, half-century career and extensive collection of RR war stories and photographs can be found on Wx4's pages devoted to him:
52 Years in the Shops

NEW 7-16-2018: 40 additional drawings, as indicated by a "# "
xxNEW 7-29-2020: 3 additional drawings, as indicated in blue

For 1935 & 1942 rosters of active steam locos, see:
"Safety valve application" charts under "Safety Valves", below

rev. = revised_____ri. = reissued

Air Brake Systems

Air brake test device, single car; 11-18-29, last rev. 9-23-37
Air compressor copper coupling; 8-2-38, rev. 9-29-38
- Letter accompanying; 10-4-38
Westinghouse air pump mount; partial drawing; 9-12-13
Emergency brake valve; 10-1-45, rev. 2-2-46
# Westinghouse compressor port machining; 9-30-36
# Westinghouse air compressor port modifications; 1-14-35
# Letter of explanation attached to above two drawings; 12-10-37
# Emergency valve rubber facing tool; 6-6-44
# triple valve cleaner (1); no date
# legend detail for above
# triple valve cleaner (2); no date

Bells

C.S. 92 lb. bell; 12-24-21, ri. 3-17-43
Bell ringer; 6-16-38, reissued 3-18-46

Booster engines

Crankshaft bearing, Franklin; 1-9-22
Axle bearing cap bolt; 2-13-50
Cylinder cock; 2-1-24
Piston; 10-3-22, ri. 11-7-44
Cut-off valve; 8-31-25; reissued 2-18-30
# Common Standard booster operating latch details; 10-9-37
NEW 7-29-2020 Franklin Booster piping circa 1952?

Cylinder cocks

Steam operated; 3-5-46
Steam operated; 6-22-43, rev. 7-7-43
Pneumatic; 6-16-26
Prime Man. duplex steam; 7-13-43, ri. 9-19-44
- Parts list; 10-25-46
Prime Man. duplex steam piping; 9-3-43
# Common Standard cylinder cock & piping: 7-30-46

Diesel locomotives

Electro Motive Corp. piston rings; 6-19-41, rev.6-15-45
Automatic shutter control piping, classes DS-8 & DS-111; 11-19-51, rev 5-13-52
Speed recorder bracket & application; 5-26-52

Domes

Auxiliary; 5-29-26; ri. 4-21-38

Feedwater heaters

Outside "By Pass"; 5-28-41, ri. 5-18-42
Choke fitting for outside by pass; 3-6-42
Lubricator fitting; 10-1-24
FWH check valve type/lift chart; 2-14-44
- Letter accompanying; 3-2-44
Steam & pump piston spacing; 10-29-35
Piston rods - Worthington; 7-27-34, rev. 1-17-46
Follower type pump piston; 6-18-35
Bucket spindle, Worthington Type B; 8-30-28
Pump springs testing device; 12-10-35, rev. 2-12-36
Exhaust check valve, Worthington Type BL; 3-7-30, rev. 9-11-31
Exhaust check valve angle; 2-19-30
- Letter referencing previous two drawings; 9-24-37
Steam strainer, Worthington; 8-6-25, ri. 4-8-42
# piston spacing, Worthington (1); 6-18-35
# piston spacing, Worthington (2); 10-9-35, rev. 4-9-38
# spring testing device, Worthington; 12-10-35, ri. 2-12-36

Gauges: cocks and fittings

Steam gage cock; 4-20-33, ri. 6-28-44
Gage cock, double seated; 7-7-43, ri. 5-19-47
Gage cock; 4-26-26, ri. (date: post 1935?)
Steam gage fitting; 4-24-29, ri 9-5-44
Water gage assembly; 8-14-26, ri. 4-1-40
Water gage fittings; 6-9-43, ri. 3-8-49
# Common standard steam gage cock, small locos; 12-22-26, ri. 11-21-38
# Nathan Common Std. reflex water gage; 4-30-37, ri. 12-23-4?
# Water gage assembly (backhead arrangement); ?-?-27, ri. 6-3-47
# Water gage cock, Common Standard (1); 8-28-37, ri. 4-8-42
# Water gage cock, Common Standard (2); 4-?-?, ri. 12-15-41
# Water Gage Fittings, Common Standard; 4-26-26, ri. 5-18-41
NEW 7-29-20 Water heights on water gauge by operating division - prior to 1943

Injectors

3 handled monitor injector #10, approved 6-22-04; 6-30-16, ri. 2-18-37
2 1⁄2" injector steam valve; 9-15-25, ri. (10-14-30?)
Injector handles; 4-26-16
# Injector nozzle spacing, Nathan (1); 4-8-22, rev. 8-10-37
# Reverse side of above
# Injector nozzle spacing, Nathan (2); 4-10-22
# Injector nozzle spacing, Nathan (3); 4-10-22
# Nathan Simplex "R" injector; no date

Lubricators

3 feed 1918 bull's eye; 2-10-32
# 5 feed 1918 bull's eye, Nathan; no date
# 6 feed type A-6 bull's eye w/aux. pipes; (improved copy) 1-11-19, ri 2-10-32
7 feed type 166 bull's eye; 9-24-23, ri. 2-10-32
Type DV-3 mechanical; 12-28-27, ri. 11-22-46
Type DV-2 mechanical; x-x-192x, ri. x-x-1946
Boiler valve details; 4-14-15, ri. 6-15-26
Mechanical lubr. terminal check , type DA; 9-12-39, ri. 11-22-46
Valve adapters; 3-14-38, ri. 2-19-42
Filling hole cover, proposed for type DV; 9-30-42, rev. 10-29-43

Miscellaneous

Cab heater piping; 12-29-30; ri. 4-30-41
Coupling flanges; 11-2-29, rev. 11-5-34
Drawbar shortener (sketch); 3-26-27
Packing leathers, various lineside devices; 11-17-02, rev. 3-25-03
Pipe elbow & nipple; 1-27-42
Polishing disks; 1-4-30, rev. 7-15-31
Air operated smoke deflector; 6-14-22, rev 7-9-24
Boiler test plate; 10-6-15, ri.3-25-35
3" pipe coupling(?) - pencil sketch; undated
Support for water column boiler spud; 9-14-34
Cold water pump weights; 8-22-38
# Tools for cutting emory cloth and paper gaskets; 6-17-44
# Water column, Common Standard; 7-23-29
# Water column details, Common Standard; 7-23-29, ri. 6-9-42
# Water column spud, Common Standard; 5-12-36, ri. 7-30-43
NEW 7-29-20 Low water drop plugs 2-1-1947

Misc. valves & cocks

C.S. blow off cock; ?
Boiler check valve, Worthington; 11-22-41
Boiler check valve cap; 6-19-23
Inside valve stem, 4-10-2 #5041 - pencil sketch; undated
# Boiler check valve maintenance; 10-16-42; ri 5-20-43

Passenger cars

Supporting bracket, Waukesha air conditioner; 6-3-43

Power reverse

ALCo type E, gen. arrangement x-section: 7-23-24, ri.3-28-34
ALCo type E, gen. arrangement - front & back; 7-23-24, ri. 3-28-34
As previous, positive copy; 7-23-24, ri. 3-28-34
ALCo type G, gen arrangement - front ; 8-24-39, ri. 3-28-46
ALCo type G, gen. arrangement - back; 8-24-39, ri. 3-28-46
Crosshead, ALCo type E or G; 10-4-24, ri. 5-5-47
ALCo (type E?) details; 3-26-23, ri. date?
# Piston & rod for loco class P-4; (improved copy) 5-20-27
Piston packing cup dimensions; 6-24-38
Valve handle - cab; 9-17-43
7" Ragonnet cyl. w/ALCo valve; date?
- Accompanying letter; 5-29-39
- Removable valve seat, per letter; 2-4-37
7" & 9" Ragonnet piston & rod - EP&SW locos; 4-19-26, rev. 6-3-35
# Common Standard Ragonnet / Alco for Class A-6; (9-24-37?), ri. (3-11-43?)

Respirators, crew

Piping - negative image; 12-17-42, ri. 12-18-46
Piping, positive image; 12-17-42, ri. 12-18-46
Filter; 10-9-39, rev. 1-23-43
Filter; 2-6-46

Safety valves

Safety valve applications chart, for locos by number; 11-15-27,
rev. ?-31-42
# Safety valve applications charts for locos by number; 12-15-27,
rev.2-25-35
NOTE: the revised dates of the above two charts presumably show active, under repair and stored serviceable locomotives; not deadlined locos
# Safety valve, Ashton Type "F" installation / repair; no date
Drop pit table safe# Safety valve applications for locos by number; 12-15-27, rev. 2-25-35 - this chart presumably shows active and stored serviceable locomotives for the latter date; not deadline locos
